Square Rubber Edge Protector 8x10mm for 6mm Panels - 25m EPDM
£202.78incl. VAT
Not sure it's the right trim? Ask a person.
Product details
Durable square channel rubber edge trim for panel protection.
This 8mm x 10mm square channel rubber edge trim is designed specifically for 6mm panels, providing a robust solution for protecting edges and ensuring a tidy finish. With a roll length of 25m, it is perfect for larger projects and batch fabrication, offering flexibility and durability to withstand handling and wear.
Key Features
- Designed for 6mm panel thickness
- Overall depth of 10mm for effective edge coverage
- 25m roll length for extensive applications
- Flexible EPDM material absorbs impacts and reduces wear
- Straight sided channel for a secure fit on flat edges
Specifications
- Profile: Square Channel
- Section Size: 8mm x 10mm
- Panel Thickness Range: Suitable for 6mm panels
- Roll Length: 25m
- Material: EPDM
Applications
- Fabricated panels and access covers
- Machinery guards and commercial equipment edges
- Workshop assemblies and maintenance tasks
- Batch fabrication and site work
Sizing questions
How do I measure my panel thickness?
Use callipers or a micrometer on a bare edge, not over paint, powder coat or a gasket. If the edge already has a lip or fold, measure the thickest point the trim will sit over.
Two sections fit my panel — which one?
The panel range is what decides the fit. The section size changes how far the trim reaches over each face, so a larger section covers a rough or damaged edge further back.
Which length should I buy?
Measure the full run of the edge and allow a little extra for cuts at corners. Longer rolls mean fewer joins on long runs.
