SKU EDGE006-5M
Square Rubber Edge Protector 6x9mm for 6mm Panels - 5m EPDM
£30.88incl. VAT
Not sure it's the right trim? Ask a person.
Product details
Durable square channel rubber edge trim for 6mm panels.
This EPDM rubber edge trim is designed specifically for 6mm panels, providing robust protection for edges while ensuring a neat appearance. With a roll length of 5m, it is suitable for various applications including short runs and site fittings.
Key Features
- Designed for 6mm panel thickness
- Overall depth of 8mm and width of 9mm
- 5m roll length for versatile application
- Made from durable EPDM for long-lasting use
- Easy to cut for custom lengths
Specifications
- Profile: Square Channel
- Section Size: 9mm width x 6mm height
- Panel Thickness Range: 6mm
- Roll Length: 5m
- Material: EPDM
Applications
- Fabricated panels and access covers
- Machinery guards and commercial equipment
- Workshop assemblies and repairs
- Sample testing and short installation runs
Sizing questions
How do I measure my panel thickness?
Use callipers or a micrometer on a bare edge, not over paint, powder coat or a gasket. If the edge already has a lip or fold, measure the thickest point the trim will sit over.
Two sections fit my panel — which one?
The panel range is what decides the fit. The section size changes how far the trim reaches over each face, so a larger section covers a rough or damaged edge further back.
Which length should I buy?
Measure the full run of the edge and allow a little extra for cuts at corners. Longer rolls mean fewer joins on long runs.
