SKU EDGE012
Square Rubber Edge Protector 24x15mm for 9mm Panels - 30m EPDM
£577.54incl. VAT
Not sure it's the right trim? Ask a person.
Product details
Durable square channel rubber edge trim for effective panel protection.
This 30m roll of EPDM square channel rubber edge trim is designed for 9mm panels, providing a reliable solution for safeguarding edges against damage. Its robust profile ensures a firm grip on thicker panels, making it ideal for various industrial and vehicle applications.
Key Features
- Designed for 9mm panel thickness
- Overall depth of 27mm for enhanced coverage
- 30m roll length for extensive use
- Square channel profile for a neat finish
- Made from durable EPDM material
Specifications
- Profile: Square channel
- Section size: 24mm x 15mm
- Panel thickness range: 9mm
- Roll length: 30m
- Material: EPDM
Applications
- Thicker panels and boards
- Vehicle and trailer bodywork edges
- Industrial covers and guards
- Batch fabrication and maintenance work
Sizing questions
How do I measure my panel thickness?
Use callipers or a micrometer on a bare edge, not over paint, powder coat or a gasket. If the edge already has a lip or fold, measure the thickest point the trim will sit over.
Two sections fit my panel — which one?
The panel range is what decides the fit. The section size changes how far the trim reaches over each face, so a larger section covers a rough or damaged edge further back.
Which length should I buy?
Measure the full run of the edge and allow a little extra for cuts at corners. Longer rolls mean fewer joins on long runs.
