DN 20 DIN Self-Adhesive Flange Disc – 58mm, Neoprene

Self-adhesive neoprene rubber disc for full-face protection of DN 20 DIN flanges during storage, transport and installation.

These protective discs seal and shield the raised face of DIN flanges, preventing gasket damage, contamination and moisture ingress. Made from 70 Shore neoprene rubber with a low-tack adhesive backing, they apply cleanly without residue and resist heat, oils, acids, alkalis and petroleum products across a wide temperature range.

Key Features

• 70 Shore neoprene rubber construction for durability and flexibility
• Low-tack self-adhesive backing – applies and removes cleanly with no residue
• Full-face protection for DIN flanges up to 160 bar
• Resistant to heat, oils, acids, alkalis and petroleum products
• Operating temperature range –15°C to +100°C
• Quick application and removal on site

Specifications

• Nominal size: DN 20
• Disc diameter: 58 mm
• Standard: DIN
• Material: neoprene rubber, 70 Shore
• Backing: low-tack self-adhesive
• Pressure rating: up to 160 bar
• Temperature range: –15°C to +100°C

Applications

• Protection during flange storage and inventory management
• Sealing and safeguarding during transport and logistics
• Installation preparation and on-site handling
• Industrial pipework and plant maintenance
• Oil and gas facility operations
