SKU FFFP001
DN 10 Full Face Flange Protector – 86mm, Yellow LDPE
Not sure it's the right size? Ask a person.
Product details
Full face flange protector with flexible bore ribs for DN 10 pipe flanges, moulded in yellow LDPE.
This protector fully covers and seals the flange face with an integral stem that inserts into the bore, preventing accidental displacement during handling and transport. The secure fit makes it ideal for production, storage and maintenance environments where cover caps might shift. Manufactured from robust low-density polyethylene, it resists moisture, dirt, paint and most oils.
Key Features
- Flexible bore ribs grip the flange bore for secure retention
- Full face coverage protects sealing surfaces and gasket seats
- Resists moisture, dirt, paint and common oils
- Moulded from high-quality LDPE plastic
- Bright yellow for easy visibility on-site
Specifications
- Standard: DN 10
- Nominal pipe size: 3/8"
- Head diameter: 86mm
- Material: LDPE
- Colour: Yellow
Applications
- Flange face protection during manufacturing and assembly
- Secure cover for stored or inactive pipework
- Transportation and logistics protection
- Maintenance shutdown protection
- Environments where a tight fit is essential
Sizing questions
Which rating do I need?
Match the class or PN rating stamped on the flange, so the bolt holes line up.
ANSI or DIN — which is my flange?
ANSI / ASME flanges are sized in inches (for example 4") with a pressure class such as 150 or 300. DIN / EN flanges are sized in DN (for example DN 100) with a PN rating. The standard and size are normally stamped on the flange rim.
Does it come off before assembly?
Yes — take the protector off before the gasket goes in.
