SKU FLC033-B
8" Class 150 Flange Stud Hole Insert - Blue LDPE
£18.00incl. VAT
Not sure it's the right size? Ask a person.
Product details
Blue LDPE stud hole insert designed to protect the bolt holes and gasket face of an 8" 150 Class pipe flange.
This flange protector features four ribs that push into the stud holes around the flange perimeter, offering a cost-effective alternative to full-face protectors. The durable LDPE construction resists moisture, dirt, paint and most oils, making it ideal for safeguarding expensive flange equipment during production, transportation, storage and maintenance work.
Key Features
- Four ribs engage stud holes for quick, tool-free installation
- LDPE material resists moisture, dirt, paint and common oils
- Protects gasket face and bolt holes from contamination and damage
- Lightweight and cost-effective flange protection solution
- Suitable for oil and gas, refining and hydraulic applications
Specifications
- Material: LDPE
- Colour: Blue
- Nominal Diameter: 8"
- Pressure Class: 150
Applications
- Oil and gas refining equipment protection
- Hydraulic system flange safeguarding
- Flange protection during transportation and storage
- Maintenance and production facility use
Sizing questions
Which class do I need?
Use the pressure class stamped on the flange rim. Inserts are sized to the bolt holes of that class, so an insert for a different class may not fit.
How many do I need?
One insert per bolt hole. The bolt-hole count depends on the flange size and class — count the holes on your flange.
ANSI or DIN — which is my flange?
ANSI / ASME flanges are sized in inches (for example 4") with a pressure class such as 150 or 300. DIN / EN flanges are sized in DN (for example DN 100) with a PN rating. The standard and size are normally stamped on the flange rim.
