SKU FLC024
3" Class 900 Flange Stud Hole Insert - Black LDPE
£11.34incl. VAT
Not sure it's the right size? Ask a person.
Product details
Black LDPE stud hole insert designed to protect 3" 900 Class flange bolt holes and gasket faces.
This flange protection insert features four ribs that push into the stud holes around a flange to hold it securely in place. Manufactured from high-quality low-density polyethylene, it shields the critical flange face from moisture, dirt, paint and most oils during production, storage, transportation and maintenance work.
Key Features
- Four ribs engage stud holes for secure fit and easy removal
- High-quality LDPE construction resists moisture and contamination
- Quick to fit with no tools required
- Cost-effective alternative to full-face protectors
- Protects gasket sealing surfaces from damage
Specifications
- Nominal flange size: 3"
- Pressure class: 900
- Material: LDPE (low-density polyethylene)
- Colour: Black
- Stud hole engagement: four ribs
Applications
- Oil and gas refining operations
- Hydraulic system maintenance and storage
- Pipeline flanges during fabrication and assembly
- Flange protection in transit and warehousing
- Equipment maintenance downtime
Sizing questions
Which class do I need?
Use the pressure class stamped on the flange rim. Inserts are sized to the bolt holes of that class, so an insert for a different class may not fit.
How many do I need?
One insert per bolt hole. The bolt-hole count depends on the flange size and class — count the holes on your flange.
ANSI or DIN — which is my flange?
ANSI / ASME flanges are sized in inches (for example 4") with a pressure class such as 150 or 300. DIN / EN flanges are sized in DN (for example DN 100) with a PN rating. The standard and size are normally stamped on the flange rim.
