SKU FLC022-B
3" Class 150 Flange Stud Hole Insert - Blue LDPE
£9.60incl. VAT
Not sure it's the right size? Ask a person.
Product details
Blue LDPE stud hole insert for 3" 150 Class flanges, protecting bolt holes and sealing surfaces.
This flange protector features four ribs that push into the stud bolt holes around a flange face, shielding the gasket area and sealing surface from damage, contamination and corrosion. Ideal for protecting costly equipment during production, transportation, storage and maintenance operations. Lightweight, quick to fit and cost-effective across oil and gas refining, hydraulics and general pipework applications.
Key Features
- Four-rib design pushes firmly into stud holes for secure protection
- High-quality LDPE resists moisture, dirt, paint and most oils
- Quick and simple installation requiring no tools
- Protects gasket face and sealing surfaces during storage and transit
- Cost-effective alternative to full-face flange protectors
Specifications
- Material: LDPE (low-density polyethylene)
- Colour: Blue
- Nominal Diameter: 3"
- Pressure Class: 150
Applications
- Oil and gas refining and production facilities
- Hydraulic systems and equipment protection
- Flange protection during manufacture and assembly
- Storage and transportation of pipe flanges
- Maintenance and overhaul operations
Sizing questions
Which class do I need?
Use the pressure class stamped on the flange rim. Inserts are sized to the bolt holes of that class, so an insert for a different class may not fit.
How many do I need?
One insert per bolt hole. The bolt-hole count depends on the flange size and class — count the holes on your flange.
ANSI or DIN — which is my flange?
ANSI / ASME flanges are sized in inches (for example 4") with a pressure class such as 150 or 300. DIN / EN flanges are sized in DN (for example DN 100) with a PN rating. The standard and size are normally stamped on the flange rim.
