SKU FLC005-B
3/4" Class 300/600 Flange Stud Hole Insert - Blue LDPE
Not sure it's the right size? Ask a person.
Product details
Four-rib stud hole insert in blue LDPE for 3/4" 300/600 class flanges; quick-fit gasket face protection.
Designed for fabricators, maintenance teams and site engineers handling flanged pipework, this stud hole insert features four ribs that engage into the bolt holes around a flange face. The rigid LDPE construction shields the gasket surface from moisture, dirt, paint and most oils during production, transportation, storage and maintenance operations.
Key Features
- Four ribs push into stud holes for secure, indexing fit
- High-density LDPE resists moisture, dirt, paint and oils
- Quick and cost-effective to install; no tools required
- Sized for 3/4" nominal diameter, 300/600 class flanges
- Blue colour for easy visibility and identification on site
Specifications
- Material: LDPE
- Colour: Blue
- Nominal Diameter: 3/4"
- Pressure Class: 300/600
- Design: Four ribs for stud hole engagement
Applications
- Oil and gas refining and production operations
- Hydraulic system flange protection during commissioning and maintenance
- Flange preservation in storage yards and during transit
- Protection during plant shutdowns and equipment overhauls
Sizing questions
Which class do I need?
Use the pressure class stamped on the flange rim. Inserts are sized to the bolt holes of that class, so an insert for a different class may not fit.
How many do I need?
One insert per bolt hole. The bolt-hole count depends on the flange size and class — count the holes on your flange.
ANSI or DIN — which is my flange?
ANSI / ASME flanges are sized in inches (for example 4") with a pressure class such as 150 or 300. DIN / EN flanges are sized in DN (for example DN 100) with a PN rating. The standard and size are normally stamped on the flange rim.
