SKU FLC004
3/4" Class 150 Flange Stud Hole Insert - Black LDPE
£5.28incl. VAT
Not sure it's the right size? Ask a person.
Product details
Stud hole insert cap for 3/4" 150 Class flanges, moulded from high-density polyethylene to shield the flange face and bolt holes.
This flange protector features four ribs that push into the stud holes around the flange perimeter, holding the cap securely in place without requiring tools or fittings into the bore. Manufactured from LDPE plastic, it provides durable protection against moisture, dirt, paint and most oils during production, transportation, storage and maintenance work.
Key Features
- Four integral ribs lock into flange stud holes for secure, tool-free installation
- High-density polyethylene (LDPE) construction resists moisture, dirt and most oils
- Designed for 3/4" nominal diameter, 150 Class pressure-rated flanges
- Cost-effective alternative to full-face bore-fitting protectors
- Quick to fit and remove without special equipment
Specifications
- Nominal pipe size: 3/4"
- Flange pressure class: 150
- Material: LDPE plastic
- Colour: Black
- Fixing method: Stud hole ribs (no tools required)
Applications
- Oil and gas refining plant and terminal operations
- Hydraulic system assembly and maintenance
- Flange protection during production and transportation
- Storage protection for costly flange equipment
- Maintenance workflows where frequent flange access is required
Sizing questions
Which class do I need?
Use the pressure class stamped on the flange rim. Inserts are sized to the bolt holes of that class, so an insert for a different class may not fit.
How many do I need?
One insert per bolt hole. The bolt-hole count depends on the flange size and class — count the holes on your flange.
ANSI or DIN — which is my flange?
ANSI / ASME flanges are sized in inches (for example 4") with a pressure class such as 150 or 300. DIN / EN flanges are sized in DN (for example DN 100) with a PN rating. The standard and size are normally stamped on the flange rim.
