SKU FD015
20" ANSI Self-Adhesive Flange Disc - 590mm, Neoprene
£64.42incl. VAT
Not sure it's the right size? Ask a person.
Product details
Self-adhesive neoprene rubber disc for full-face protection of 20" ANSI pipe flanges.
These round discs combine a 70 Shore neoprene rubber face with a low-tack adhesive backing to seal and protect the flange sealing surface. They stick firmly during storage and transit, yet remove cleanly without leaving residue or damaging the flange face. Suitable for use across oil, gas, water and chemical processing applications.
Key Features
- 70 Shore neoprene rubber construction
- Low-tack adhesive backing for clean removal
- Full-face flange protection
- Temperature range −15 °C to +100 °C
- Resistant to acids, alkalis, oils and petrol
- Cost-effective consumable for industrial maintenance
Specifications
- Standard: ANSI
- Flange size: 20"
- Disc diameter: 590 mm
- Material: Neoprene rubber with adhesive backing
Applications
- Pipe flange protection during storage
- Contamination prevention in transit
- Oil and gas pipeline systems
- Water and chemical processing plants
- Industrial maintenance and installation
Sizing questions
Which disc size do I need?
Pick the disc for your flange standard and nominal size. The disc diameter is in the title so you can check it against the flange face.
ANSI or DIN — which is my flange?
ANSI / ASME flanges are sized in inches (for example 4") with a pressure class such as 150 or 300. DIN / EN flanges are sized in DN (for example DN 100) with a PN rating. The standard and size are normally stamped on the flange rim.
Does it come off before assembly?
Yes — peel the disc off before the gasket goes in.
