SKU FLC017-B
2" Class 300/600 Flange Stud Hole Insert - Blue LDPE
£7.20incl. VAT
Not sure it's the right size? Ask a person.
Product details
Blue LDPE stud hole insert designed to protect 2" flange bolt holes and gasket faces from contamination and damage.
Four integral ribs engage the stud holes around the flange perimeter, holding the cap firmly in place without requiring the flange bore. Manufactured from high-quality low-density polyethylene, it resists moisture, dirt, paint overspray and most mineral oils during production, transportation, storage and maintenance operations.
Key Features
- Four ribs push into stud holes for secure, tool-free installation
- LDPE material resists moisture, dirt, paint and oil contamination
- Quick to fit and easy to remove without damage to flange
- Cost-effective alternative to full-face flange covers
- Suitable for 300/600 Class pressure rated flanges
Specifications
- Nominal diameter: 2"
- Class pressure rating: 300/600
- Material: LDPE
- Colour: Blue
Applications
- Oil and gas refining equipment protection
- Hydraulic system flange protection
- Storage and transit protection for pipe flanges
- Maintenance work on high-value flange assemblies
- Production floor flange safeguarding
Sizing questions
Which class do I need?
Use the pressure class stamped on the flange rim. Inserts are sized to the bolt holes of that class, so an insert for a different class may not fit.
How many do I need?
One insert per bolt hole. The bolt-hole count depends on the flange size and class — count the holes on your flange.
ANSI or DIN — which is my flange?
ANSI / ASME flanges are sized in inches (for example 4") with a pressure class such as 150 or 300. DIN / EN flanges are sized in DN (for example DN 100) with a PN rating. The standard and size are normally stamped on the flange rim.
