SKU FLC002-B
1/2" Class 300/600 Flange Stud Hole Insert - Blue LDPE
Not sure it's the right size? Ask a person.
Product details
Blue LDPE stud hole insert designed to plug and protect the bolt holes of 1/2" ANSI 300/600 Class flanges.
This flange protector features four ribs that push into the stud holes around a flange face, shielding the sealing surface and bolt holes from moisture, dirt, paint and oils during production, transportation, storage and maintenance. Manufactured from high-quality low-density polyethylene, it provides a quick, cost-effective protection solution for critical flange equipment in refining, oil and gas, and hydraulic applications.
Key Features
- Four ribs engage stud holes for secure fit
- Protects gasket face and sealing surface
- Resists moisture, dirt, paint and oils
- Fast, tool-free installation
- Durable LDPE construction
- Cost-effective alternative to full-face protectors
Specifications
- Material: LDPE
- Colour: Blue
- Nominal Size: 1/2"
- Standard: ANSI
- Class Rating: 300/600
Applications
- Oil and gas refining pipework
- Hydraulic systems and components
- Flange protection during manufacture and assembly
- Transit and warehouse storage
- Maintenance and turnaround work
Sizing questions
Which class do I need?
Use the pressure class stamped on the flange rim. Inserts are sized to the bolt holes of that class, so an insert for a different class may not fit.
How many do I need?
One insert per bolt hole. The bolt-hole count depends on the flange size and class — count the holes on your flange.
ANSI or DIN — which is my flange?
ANSI / ASME flanges are sized in inches (for example 4") with a pressure class such as 150 or 300. DIN / EN flanges are sized in DN (for example DN 100) with a PN rating. The standard and size are normally stamped on the flange rim.
